Lian-Li O11 Dynamic Mini Black Case
Full description Lian-Li.
Think Big. Build Small.
O11D MINI adding to the O11 Dynamic series, the classic and modern looking. A case that would accommodate the maximum number of water-cooling configurations without being oversized. With a modular back panel design, the user has the option to choose from 3 slots/ 5 slots/ 7 slots I/O shield to optimize the case to the configuration of user’s choice. Supports mini-ITX, micro-ATX, ATX, and E-ATX motherboard sizes and up to 9 fans to cool the chassis.
CONFIGURATION OF YOUR CHOICE – MODULAR BACK PANEL
Decide how many expansion slots you need. Calculate the size of your fans & accessories.
Pick your motherboard type. 3 kinds of back panels to meet your demand!
SIDE RADIATOR CONFIGURATION WITH LONG GPU
The 30mm space behind the side fan / radiator bracket allows users to mount fans, thus efficiently intake fresh air to directly cool the radiator and leaves enough space to install long GPUs in this compact case.
WITH WATER COOLING IN MIND – MODULAR PUMP STAND
Friendly to custom water cooling users, the three different pump stands included can accommodate different scenarios.
With a blend of brushed aluminium and tempered glass, the O11D Mini not only looks classic and modern, but also has a high-quality feel and touch on the exterior.
A SERIES OF O11 DYNAMIC
As a member of the O11 family, the O11D Mini is designed to support a maximum number of radiators to optimize the water-cooling potential, and this even with a smaller frame.
DUAL-CHAMBER DESIGN FOR CABLE MANAGEMENT
Carried from the design of the O11D series, cables quickly pass to the second chamber through rubber grommets. Multiple tie points and Velcro strap channels are provided to tidy up the cables while the SSD mounting bar helps keep the loose cables all snuggled up to ensure a clean look and prevent the right-side panel from not closing or bulging.
COMPLETE DUST PROTECTION
All 3 ventilation intake sides are equipped with magnetic dust filters and a removable dust tray to prevent the dust from entering the case.
German Engineering Approved
The O11 Dynamic series from LIAN LI is developed in collaboration with DER8AUER, a world-renowned German overclocking, water cooling, and gaming evangelist. Always looking for ways to improve computer design and performance, DER8AUER volunteered his time to review and test the design concepts of the O11D series.
Starting with the first O11 Dynamic and up until the most recent models of the O11D series, LIAN LI appreciates the input from DER8AUER which helped make the O11D series exceptional cases, especially in terms of custom water cooling compatibility, ease of build, and features offered. As a result, DER8AUER’s seal of approval is elegantly displayed beside the LIAN LI logo, standing as a statement of quality and reliability.
|Product Name||O11 Dynamic MINI|
|MODEL||O11D Mini-X||O11D Mini-W||O11D Mini-S|
|DIMENSIONS||(D)420mm X (W)269.5mm X (H)380mm|
|MOTHERBOARD||E-ATX (Max 280 mm wide)/ATX/ Micro-ATX/ Mini-ITX|
4 mm Tempered Glass
2mm Aluminium (top and left panel)
|FAN SUPPORT||Top: 3x 120mm or 2x 140mm
Side: 2x 120mm or 2x 140mm
Bottom: 3x 120mm or 2x 140mm
Rear: 1x 120mm
|RADIATOR SUPPORT||Top: 360mm or 280mm or 240mm radiator
Side: 240mm or 280mm radiator
Bottom: 360 or 280mm or 240mm radiator
|GPU LENGTH CLEARANCE||395mm|
|CPU COOLER HEIGHT CLEARANCE||170mm|
|DRIVES||Right side 2 x 2.5″ SSD + back plate 2 x 3.5″ HDD (or SSD)|
|EXPANSION SLOTS||3 or 5 or 7 slots (depends on back panel)|
|IO PORTS||2 x USB 3.0, 1 x USB 3.1 TYPE-C, 1 x HD Audio, Power Button|
|DUST FILTERS||1 x Top, 1 x Bottom, 2 x Side|
Lian-Li O11 Dynamic Mini Black Case
Contact us if you would like to enquire about this product
