HAVN BF 360 Mid-Tower E-ATX Desktop Gaming PC Case White – HVN-CA-BF360-01
Full description HAVN.
- The HAVN BF 360 Mid-Tower E-ATX Desktop Gaming PC Case is built for premium showcase and performance systems, combining broad hardware compatibility, clean internal layout options, and strong airflow potential in a sleek white tempered glass design.
- With support for E-ATX, ATX, Micro-ATX, and ITX motherboards, plus clearance for graphics cards up to 410mm long and CPU air coolers up to 195mm high, the BF 360 is well suited to powerful modern gaming builds.
- The case supports up to 7 fans and large radiator options including top 360mm and front 420mm, giving builders excellent flexibility for both high-end air cooling and custom or AIO liquid cooling setups.
- A built-in PWM fan repeater with 6 total ports helps simplify cable management and fan control, while the case also includes practical support for large GPUs, extensive storage options, and well-planned internal expansion space.
- Premium touches such as USB Type-C front I/O, integrated dust filters, tempered glass panels, and support for up to 4.5-slot GPUs make this case an excellent option for enthusiasts who want both strong thermals and a refined display build.
| Specifications | |
|---|---|
| Brand | HAVN |
| Series | BF 360 |
| Model | HVN-CA-BF360-01 |
| Product Type | Mid-Tower Desktop Gaming PC Case |
| Colour | White |
| Case Information | |
| Form Factor | Mid Tower |
| Material | SGCC sheet metal, tempered glass, ABS, nylon, silicon, zinc alloy, NdFeB magnets |
| Motherboard Support | E-ATX, ATX, Micro-ATX, ITX |
| Expansion Slots | 7 |
| GPU Support | 1 – 4.5 Slots |
| Dimensions & Clearance | |
| Case Dimensions | 515 x 254 x 522.6 mm |
| Net Weight | 13.63 kg |
| Graphics Card Clearance | Length: Up to 410 mm, Width: Up to 195 mm |
| CPU Tower Cooler Clearance | Height: Up to 195 mm |
| RAM Clearance | If radiator and fans thickness is greater than 80 mm: 280 mm – 40 mm / 360 mm – 60 mm |
| Power Supply Support | ATX |
| PSU Clearance | Length: Up to 200 mm (Clearance – 260mm) |
| Cooling Support | |
| Fan Support | Maximum Amount: 7 |
| Top Fan Support | 2 x 180 mm, 2 x 140 mm, 3 x 120 mm |
| Front Fan Support | 2 x 180 mm, 3 x 140 mm, 3 x 120 mm |
| Rear Fan Support | 1 x 140 mm, 1 x 120 mm |
| Fan PWM Repeater | 1 x PWM repeater, 6 ports total |
| Repeater Location | 1 x Cable Management Tray |
| Fan Connectors | 6 ports per repeater x 4-pin PWM |
| Fan Rated Voltage | 12V |
| Fan Safety Current | Up to 2.6A across 6 ports |
| Power Connector | 1 x SATA Power |
| Power Safety Current | 1 x SATA connector power input, 12V – 2.6A (max) |
| Liquid Cooling Support | Top: 240, 280, 360 mm, Front: 240, 280, 360, 420 mm |
| AIO Thickness Support | Up to 60 mm |
| Storage | |
| Right Mount Storage Bays | 2 x 3.5″, 4 x 2.5″ |
| Cable Management Tray Storage Bay | 1 x 3.5″, 2 x 2.5″ |
| Included Storage Bays | 2 x (2 x 3.5″ / 4 x 2.5″) |
| Front I/O | |
| USB Type-C | 1 x USB 3.2 Gen 2 Type-C |
| USB Type-A | 2 x USB 3.2 Gen 1 Type-A |
| Audio | Audio Jack x1 |
| Buttons | Power & Reset Button x1 |
| Dust Management | |
| Front Dust Filter | 1 (Built-in) |
| Top Dust Filter | 1 (Built-in) |
| Rear Bottom Dust Filter | 1 (Removable) |
| Warranty Information | |
| Warranty | 1 Year Warranty |
