ASUS TUF Gaming ARGB PWM Fan Hub
Full description ASUS.
- The ASUS TUF Gaming ARGB PWM Fan Hub lets you connect and control up to six case fans, making it a practical solution for builders who want cleaner cable management and synchronized cooling and lighting in one compact hub.
- Designed for seamless system integration, it supports both 4-pin PWM fan control and 3-pin ARGB lighting, helping unify fan speed management and RGB effects for a more organized and visually consistent gaming PC build.
- With dual SATA power connectors, the hub is built to provide stable power delivery under full load, making it suitable for multi-fan setups where reliable performance and consistent lighting are important.
- Handy design touches such as visible power and operation indicators, simple magnetic mounting, and two safety fuses for overcurrent protection make installation easier while helping improve usability and protection inside the case.
- Supporting up to 9A total safety current across both fan and RGB ports, the TUF Gaming ARGB PWM Fan Hub is a strong choice for users who want dependable expansion for high-airflow, RGB-enabled desktop builds.
| Specifications | |
|---|---|
| Brand | ASUS |
| Series | TUF Gaming |
| Model | ARGB PWM Fan Hub |
| Product Type | Fan Hub |
| Fan Connectivity | |
| Fan Connector | 6 Ports x 4 pin PWM |
| Fan Rated Voltage | 12V |
| Fan Safety Current | 2A (1 port), Total 9A (6 ports) |
| RGB Connectivity | |
| RGB Connector | 6 Ports x 3 pin ARGB |
| RGB Rated Voltage | 5V |
| RGB Safety Current | 2A (1 port), Total 9A (6 ports) |
| Power | |
| Power Connector | 2 x SATA Power |
| Power Safety Current | 2 SATA Connector Power Input, 12V -> 9A Max., 5V -> 9A Max. |
| Design | |
| Mounting | Magnetic Mounting |
| Indicators | Visible Power and Operation Indicators |
| Protection | Two safety fuses for overcurrent protection |
| Dimensions | 115 x 69 x 17.7 mm |
| Weight | 81.5 g |
| Warranty Information | |
| Warranty | 1 Year Warranty |
