ASUS TUF Gaming 750W EVO 80 Plus Gold Fully Modular Desktop Power Supply – TUF-GAMING-750G-EVO
Full description ASUS.
- The ASUS TUF Gaming 750W EVO is a fully modular desktop power supply built for modern gaming and performance PCs, delivering 750W total output, ATX 3.1 support, and a compact black PSU design.
- With 80 Plus Gold efficiency and Cybenetics Platinum efficiency at 230V, this PSU is designed to deliver stable, efficient power for gaming builds, workstation PCs, graphics cards, processors, and everyday high-performance systems.
- The PSU includes modern protection features such as OPP, OVP, UVP, SCP, OCP, and OTP, helping safeguard connected components against power-related issues during demanding workloads and long gaming sessions.
- Flexible connectivity includes MB 20+4-pin, dual CPU 4+4-pin, PCI-E 16-pin 12V-2×6, PCI-E 6+2-pin, SATA, and peripheral connectors, supporting modern graphics cards, motherboards, storage, and accessories.
- A compact 140 x 150 x 86mm ATX12V design, Active PFC, >120,000-hour MTBF at 40°C, included modular cables, and 8 Year Warranty make it a reliable choice for long-term PC builds.
| Specifications | |
|---|---|
| Brand | ASUS |
| Series | TUF Gaming |
| Model | TUF-GAMING-750G-EVO |
| Colour | Black |
| Power Supply | |
| Total Output | 750W |
| Form Factor | ATX12V |
| PFC Type | Active PFC |
| ATX Standard | ATX 3.1 |
| 80 Plus Efficiency | 80 Plus Gold |
| Cybenetics Efficiency | Platinum 230V / Gold 115V |
| AC Input Range | 100–240Vac |
| DC Output Voltage | +3.3V, +5V, +12V, -12V, +5Vsb |
| Maximum Load | 20A, 20A, 62.5A, 0.3A, 3A |
| Combined Load | 110W, 110W, 750W, 3.6W, 15W |
| Protection Features | OPP, OVP, UVP, SCP, OCP, OTP |
| MTBF | >120,000 hours at 40°C |
| Cable Connectors | |
| Motherboard Connector | 1x MB 20+4-pin |
| CPU Connector | 2x CPU 4+4-pin |
| PCI-E Connector | 1x PCI-E 16-pin 12V-2×6 |
| PCI-E 6+2-pin Connector | 2x PCI-E 6+2-pin |
| SATA Connector | 4x SATA |
| Peripheral Connector | 2x Peripheral |
| Dimensions & Weight | |
| Dimensions | 140 x 150 x 86mm |
| Weight | 1.32kg |
| Included in the Box | |
| Included Items | Power cord x1 Motherboard power cable x1, 610mm CPU 1-to-2 cable x1, 650mm + 100mm PCI-E Gen 5.1 cable 16-pin-to-16-pin x1, 500mm PCI-E 1-to-2 cable, 8-pin-to-6+2-pin x1, 500mm + 100mm SATA & Peripheral 1-to-2+1 cable x2, 400mm + 120mm + 120mm TUF Gaming cable tie x3 User manual x1 |
| Warranty Information | |
| Warranty | 8 Year Warranty |
ASUS TUF Gaming 750W EVO 80 Plus Gold Fully Modular Desktop Power Supply – TUF-GAMING-750G-EVO
Contact us if you would like to enquire about this product.
