ASUS Prime AP201 Mesh Steel Micro-ATX Mid-Tower Desktop Chassis – Black
Full description ASUS.
- Quasi-Filter Mesh Panels: A mesh design comprised of over 57,000 precision-machined 1.5mm holes increases airflow and provides a compelling view of the components within your build.
- Optimized for Cooling: With support for 280 and 360mm radiators and up to six fans, the AP201 is primed to deal with the thermal onslaught of high-performance hardware.
- Industry-Leading Spatial Efficiency: Despite a 33L footprint, the AP201 supports ATX PSUs up to 180 mm long, graphics cards up to 338 mm long, custom liquid cooling, and various storage devices.
- Tool-Free Side Panels: A simple yet secure clip mechanism allows chassis side panels to be easily removed and resistant to accidental dislodging.
- Sizeable Cable-Management: The AP201 features an extended motherboard tray with strategically placed cutouts and a 32 mm gap to tuck cables out of sight.
- Front Panel USB Type-C® Support: The front panel of the AP201 features a USB 3.2 Gen 2 Type-C port, so users can enjoy transfer speeds of up to 10 Gbps.
Specifications |
|
| Brand: | ASUS |
| Series: | Prime AP201 Mesh Series |
| Model: | ASUS AP201/BLK/MESH (90DC00G0-B39000) |
| Technical Specs | |
| Motherboard Support: | Supports Micro-ATX, Mini-ITX Motherboards |
| Drive Bays: | 1x 2.5″ HDD/SSD Drive Bay |
| Up to 3x 2.5″/3.5″ Combo Drive Bays | |
| Expansion Slots: | 4x PCI Slots |
| Dust Filters: | Yes, 1x Bottom dust filter |
| Front I/O: | 1x Front-Panel USB 10Gb/s Type-C Port 2x Front-Panel USB 5Gbps Type-A Ports 2x 3.5mm Audio Jacks (Headphone, Microphone) |
| Side Panel: | Ventilated Mesh Side Panels |
| Fan Specs | |
| Pre-Installed Fans: | Rear: 1x 120mm ASUS Fan |
| Fan Support: | Front: N/A (Consumed by PSU) Top: 3x 120mm Fans or 2x 140mm Fans Rear: 1x 120mm Botto:m 2x 120mm Fans (Conflicts with Combo 2.5″/3.5″ drive mounts) |
| Radiator Support | |
| Front: | – |
| Top: | 120mm, 140mm, 240mm, 280mm, 360mm Radiator |
| Rear: | 120mm Radiator |
| Side: | – |
| Chassis Clearance Specs | |
| Cooler Height Clearance: | 170mm |
| GPU Length Clearance: | 338mm |
| PSU Length Limit: | 180mm |
| Software & Features | |
| Software Support: | – |
| Features: | Quasi-Filter Mesh Panels |
| Optimized for Cooling | |
| Industry-Leading Spatial Efficiency | |
| Tool-Free Side Panels | |
| Sizeable Cable-Management | |
| General | |
| Chassis Lighting: | – |
| PSU Support: | ATX |
| Dimensions: | 205 x 350 x 460 mm |
| Weight: | 5.8kg |
| Colour: | Black |
| Warranty Information | |
| Warranty: | 3 Year Warranty |
