APNX V1 Mid-Tower ATX Tempered Glass Desktop PC Case Black – V1-BK-v1
Full description APNX.
- The APNX V1 Mid-Tower ATX Desktop PC Case is built for clean, modern gaming systems, combining tempered glass styling, broad cooling support, and generous internal layout flexibility in a sleek black chassis.
- Designed for mainstream gaming and performance builds, it supports ATX, Micro ATX, and Mini-ITX motherboards, graphics cards up to 395mm, CPU coolers up to 170mm, and ATX power supplies up to 220mm including cables.
- Cooling flexibility is strong across the chassis, with support for multiple fan positions at the front-right, top, bottom, and rear, making it a solid option for airflow-focused gaming PC builds.
- For liquid cooling setups, the case supports radiators up to 360mm at the front-right, top, and bottom, giving builders excellent flexibility for custom loops or larger AIO cooler installations.
- Practical build-focused features such as USB 3.2 Gen 2×2 Type-C, removable filters, spacious 90mm cable management depth, and multiple storage mounting options make the APNX V1 a strong choice for tidy, high-performance desktop builds.
| Specifications | |
|---|---|
| Brand | APNX |
| Series | V1 |
| Model | V1-BK-v1 |
| Product Type | Mid-Tower Desktop PC Case |
| Colour | Black |
| Case Information | |
| Case Type | Mid Tower |
| Body Material | SGCC |
| Front Panel Material | ABS |
| Steel Thickness | 0.8mm |
| Motherboard Support | ATX, Micro ATX, Mini-ITX |
| Dimensions & Clearance | |
| Internal Dimensions | 290 x 460 x 480 mm (W x H x D) |
| Overall Dimensions | 290 x 485.5 x 500 mm (W x H x D) |
| GPU Clearance | Up to 395mm |
| CPU Cooler Clearance | Up to 170mm |
| Internal Cable Management Depth | 90mm |
| PSU Support | ATX PSU, up to 220mm |
| Drive Bays | |
| 3.5″ Drive Bays | 2 Max. |
| 2.5″ Drive Bays | 6 Max. |
| Expansion Slots | 7 |
| Cooling Support | |
| Front-Right Fan Support | 120mm x 3, 140mm x 2, or 160mm x 2 Max. |
| Top Fan Support | 120mm x 3 or 140mm x 2 Max. |
| Bottom Fan Support | 120mm x 3 or 140mm x 2 Max. |
| Rear Fan Support | 120mm x 1 Max. |
| Radiator Support | |
| Front-Right Radiator Support | 120, 140, 240, 280, 360mm |
| Top Radiator Support | 120, 140, 240, 280, 360mm |
| Bottom Radiator Support | 120, 140, 240, 280, 360mm |
| Rear Radiator Support | 120mm |
| Front I/O | |
| USB Type-C | 1 x USB 3.2 Gen 2×2 Type-C |
| USB Type-A | 2 x USB 3.2 Gen 1 Type-A |
| Audio | Audio & Mic |
| Dust Management | |
| Filters | Top (Built-in), Front-Right (Removable), Side (Removable), Bottom (Removable) |
| Warranty Information | |
| Warranty | 2 Year Warranty |
