APNX B509A Flow ARGB Mid-Tower ATX Tempered Glass Desktop PC Case Black – Flow-G-BK-v1
‘Full description APNX.
- The APNX B509A Flow ARGB is a compact mid-tower desktop PC case designed for clean, high-airflow gaming builds, combining a full mesh front panel, tempered glass side panel, and broad mainstream hardware support in a sleek black finish.
- Built for versatile system compatibility, it supports ATX, Micro ATX, and Mini-ITX motherboards, graphics cards up to 340mm, CPU coolers up to 158mm, and ATX power supplies up to 185mm including cables.
- Cooling flexibility is strong for its size, with support for front, top, PSU shroud, and rear fan placements, allowing up to 8 fan positions for improved airflow and better thermal performance in modern gaming systems.
- For liquid cooling builds, the case supports radiators up to 360mm at the front and 120mm at the rear, making it a practical option for users wanting AIO cooling support in a more compact mid-tower layout.
- Practical features such as a tempered glass side panel, top magnetic dust filter, bottom dust filter, and front I/O with USB 3.0, USB 2.0, and HD audio make the B509A Flow a strong choice for stylish and functional PC builds.
| Specifications | |
|---|---|
| Brand | APNX |
| Series | B509A Flow ARGB |
| Model | Flow-G-BK-v1 |
| Product Type | Mid-Tower Desktop PC Case |
| Colour | Black |
| Case Information | |
| Case Type | Mid Tower |
| Body Material | SPCC |
| Front Panel Material | ABS, SPCC |
| Steel Thickness | 0.5mm |
| Motherboard Support | ATX, Micro ATX, Mini-ITX |
| Tempered Glass Side Panel | Yes |
| Dimensions & Clearance | |
| Internal Dimensions | 200 x 440 x 350 mm (W x H x D) |
| Overall Dimensions | 206.5 x 450.5 x 400.55 mm (W x H x D) |
| GPU Clearance | Up to 340mm |
| CPU Cooler Clearance | Up to 158mm |
| Internal Cable Management Depth | 21mm |
| PSU Support | ATX PSU, up to 185mm |
| Drive Bays | |
| 3.5″ Drive Bays | 2 Max. |
| 2.5″ Drive Bays | 5 Max. |
| Expansion Slots | 7 |
| Cooling Support | |
| Front Fan Support | 120mm x 3 or 140mm x 3 Max. |
| Top Fan Support | 120mm x 2 or 140mm x 2 Max. |
| PSU Shroud Fan Support | 120mm x 2 Max. |
| Rear Fan Support | 120mm x 1 Max. |
| Radiator Support | |
| Front Radiator Support | 120, 240, 280, 360mm |
| Rear Radiator Support | 120mm |
| Front I/O | |
| USB 3.0 | 1 |
| USB 2.0 | 2 |
| Audio | HD Audio & Mic |
| Dust Management | |
| Top Dust Filter | Magnetic |
| Bottom Dust Filter | Yes |
| Warranty Information | |
| Warranty | 2 Year Warranty |
