Anycubic Wash and Cure 3 Max Ultra-large 15.1L Wash Capacity – WC3MWH0B-O
Full description Anycubic.
- The Anycubic Wash & Cure 3 Max is an ultra-large post-processing station for resin 3D printing, combining automated washing and curing in one system for large prints, batch runs, studios, workshops, and serious resin printing setups.
- With a 305 x 165 x 300mm maximum cleaning volume and 20L cleaning container capacity, it is built to handle larger resin prints while remaining compatible with most mainstream LCD printers up to 13.6 inches.
- The station supports one-click automated washing and curing, with Auto, Wash, and Cure modes that allow users to customise the post-processing workflow depending on print size, resin type, and finishing requirements.
- For curing, a 360° rotating platform, 20x 405nm LEDs, and a flexible gooseneck light deliver even UV exposure, reaching up to 25,000μW/cm² power density at an 18cm irradiation distance.
- Intelligent monitoring helps detect open covers, low voltage, blockages, and liquid inflow issues, while touch-button controls, a transparent flip-open lid, 13.5kg build, and 1 Year Warranty make it practical for regular resin workflows.
| Specifications | |
|---|---|
| Brand | Anycubic |
| Series | Wash & Cure |
| Model | Wash & Cure 3 Max |
| Product Code | WC3MWH0B-O |
| Product Type | Washing and Curing Station |
| Washing & Curing | |
| Maximum Curing Volume | 15.1L |
| Maximum Cleaning Volume | 305 x 165 x 300mm |
| Cleaning Method | Alcohol soaking + spray rinse |
| Cleaning Container Capacity | 20L |
| UV Light Configuration | 20x 405nm LEDs + gooseneck light |
| Maximum Curing Power Density | Up to 25,000μW/cm² at 18cm irradiation distance |
| Compatible Printer Models | Photon M3 MaxPhoton Mono M7 MaxMost mainstream LCD printers with build volume 13.6 inches or smaller |
| Controls & Operation | |
| Control Interface | Touch buttons |
| Operation Modes | Auto, Wash, Cure |
| Time Setting Range | Auto mode: 13–42.5 minutesWash mode: 10–39.5 minutesCure mode: 0.5–30 minutes |
| Intelligent Monitoring | Open cover, no liquid inflow, outlet blockage, and low voltage alerts |
| Rated Power | 120W |
| Dimensions & Weight | |
| Product Dimensions | 434 x 434 x 556mm |
| Product Weight | 13.5kg |
| Included in the Box | |
| Included Items | Anycubic Wash & Cure 3 Max tray x1 Detergent drum x1 Waste liquid drum x1 Clean liquid drum x1 Water tubes x4 Wrench set x1 Power adapter and power cord x1 User manual x1 |
| Warranty Information | |
| Warranty | 1 Year Warranty |
