Intel Core i5-14500 14-Core 5.0GHz LGA1700 Processor

Full description Intel.

The Intel Core i5-14500 is a desktop processor with 14 cores.
It is part of the Core i5 lineup, using the Raptor Lake Refresh architecture with Socket 1700.
Intel Hyper-Threading technology is available and effectively doubles the core-count of the P-Cores, to a total of 20 threads.
Core i5-14500 has 24 MB of L3 cache and operates at 2.6 GHz by default, but can boost up to 5 GHz, depending on the workload.
Intel’s processor supports DDR4 and DDR5 memory with a dual-channel interface. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption.

Specifications
Brand:	Intel
Series:	Intel 14th Gen Raptor Lake Series
Model:	BX8071514500
Technical Specs
Sockets Supported:	LGA 1700
Cores:	14
Threads:	20
Max Turbo Frequency:	5 GHz
Efficient-core Max Turbo Frequency:	3.7 GHz
Cache:	24 MB Intel® Smart Cache
Performance-core Max Turbo Frequency:	5 GHz
Base Power:	65w
Turbo Power:	154w
Graphics Specs
Processor Graphics:	Intel® UHD Graphics 770
Base Frequency:	–
Max Dynamic Frequency:	1.55 GHz
Graphics Output:	eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units:	32
Max Resolution (HDMI):	4096 x 2160 @ 60Hz
Max Resolution (DP):	7680 x 4320 @ 60Hz
API Support:	–
PCI Express Configurations:	Up to 1×16+4, 2×8+4
Memory Specs
Max Memory Supported:	192 GB
Memory Types:	Up to DDR5 4800 MT/s
Memory Types:	Up to DDR4 3200 MT/s
Max Memory Bandwidth:	76.8 GB/s
Software & Features
Software:	–
Features:	Intel Deep Learning Boost
	Intel Turbo Boost Technology
	Speed Shift Technology
	Hyper-Threading Technology
	Enhanced Intel SpeedStep Technology
General
Package Size:	45.0 mm x 37.5 mm
Warranty Information
Warranty:	3 Year Warranty
