Gigabyte TRX40 AORUS Master WiFi Threadripper E-ATX Motherboard
Full description Gigabyte.
- Supports 3rd Gen AMD Ryzen™ Threadripper™ Processors
- Quad Channel ECC/ Non-ECC Unbuffered DDR4, 8 DIMMs
- 12+2 Phases Infineon Digital VRM Solution with 70A Power Stage
- Advanced Thermal Design with Fins-Array Heatsink
- Intel® GbE LAN with cFosSpeed Internet Accelerator
- 3 Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Thermal Guards
- Onboard Intel® WiFi 6 802.11ax 2T2R & BT 5
SPECIFICATIONS |
|
| Brand | Gigabyte |
| Series | Socket sTRX4 |
| Model | GA-TRX40-AORUS-MASTER |
| CPU | AMD Socket sTRX4: |
| Support 3rd Generation AMD Ryzen Threadripper Processors |
|
| Chipset | AMD TRX40 |
| Memory | 8x DDR4 DIMM Sockets Supporting Up to 256 GB (32 GB Single DIMM Capacity) of System Memory |
| Quad Channel Memory Architecture | |
| Support for DDR4 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz Memory Modules |
|
| Support for ECC Un-Buffered DIMM 1Rx8/2Rx8 Memory Modules | |
| Support for Non-ECC Un-Buffered DIMM 1Rx8/2Rx8/1Rx16 Memory Modules | |
| Support for Extreme Memory Profile (XMP) Memory Modules | |
| Audio | 1x Realtek ALC4050H Codec+1 x Realtek ALC1220-VB Codec (Rear Audio) |
| 1x Realtek ALC4050H Codec+1 x ESS SABRE9218 DAC Chips (Front Audio) |
|
| Support for DTS:X Ultra | |
| High Definition Audio | |
| 2/4/5.1/7.1-Channel | |
| Support for S/PDIF Out | |
| LAN | 1x Aquantia 5GbE LAN Chip (5 Gbit/2.5 Gbit/1 Gbit/100 Mbit) (5GLAN) |
| 1x Intel GbE LAN Chip (10/100/1000 Mbit) (LAN) | |
| Wireless Communication Module | Intel Wi-Fi 6 AX200: |
| Wi-Fi 802.11a/b/g/n/ac/ax, Supporting 2.4/5 GHz Dual-Band | |
| BLUETOOTH 5.0 | |
| Support for 11ax 160MHz Wireless Standard and Up to 2.4 Gbps Data Rate *1 | |
| Expansion Slots | 2x PCI Express x16 Slots, Running at x16 (PCIEX16_1, PCIEX16_2) *2 |
| 2x PCI Express x16 Slots, Running at x8 (PCIEX8_1, PCIEX8_2) *2 | |
| 1x PCI Express x1 Slot *2 | |
| Multi-Graphics Technology | Support for NVIDIA Quad-GPU SLI and 3-Way/2-Way NVIDIA SLI Technologies |
| Support for AMD Quad-GPU CrossFire and 3-Way/2-Way AMD CrossFire Technologies |
|
| Storage Interface | Integrated in the CPU: |
| 1x M.2 Connector (Socket 3, M Key, Type 2260 /2280/22110 SATA and PCIe 4.0 x4/x2 SSD Support) (M2M) |
|
| 1x M.2 Connector (Socket 3, M Key, Type 2280 SATA and PCIe 4.0 x4/x2 SSD Support) (M2Q) |
|
| Integrated in the Chipset: | |
| 1x M.2 Connector (Socket 3, M Key, Type 2280 SATA and PCIe 4.0 x4/x2 SSD Support) (M2P) |
|
| 8x SATA 6Gb/s Connectors | |
| Support for RAID 0, RAID 1, and RAID 10 | |
| USB | Integrated in the CPU: |
| 4x USB 3.2 Gen 2 Type-A Ports (Red) on the Back Panel | |
| Integrated in the Chipset: | |
| 1x USB Type-C Port on the Back Panel, with USB 3.2 Gen 2 Support | |
| 1x USB 3.2 Gen 2 Type-A Port (Red) on the Back Panel | |
| 1x USB Type-C Port with USB 3.2 Gen 2 Support, Available Through the Internal USB Header |
|
| 4x USB 3.2 Gen 1 Ports Available Through the Internal USB Headers | |
| Chipset+2 USB 2.0 Hubs: | |
| 6x USB 2.0/1.1 Ports (2 Ports on the Back Panel, 4 Ports Available Through the Internal USB Headers) |
|
| Internal I/O Connectors | 1x 24-pin ATX Main Power Connector |
| 2x 8-pin ATX 12V Power Connectors | |
| 1x CPU Fan Header | |
| 1x Water Cooling CPU Fan Header | |
| 2x System Fan Headers | |
| 4x System Fan/Water Cooling Pump Headers | |
| 2x Addressable LED Strip Headers | |
| 2x RGB LED Strip Headers | |
| 3x M.2 Socket 3 Connectors | |
| 8x SATA 6Gb/s Connectors | |
| 1x Front Panel Header | |
| 1x Front Panel Audio Header | |
| 1x USB Type-C Port, With USB 3.2 Gen 2 Support | |
| 2x USB 3.2 Gen 1 Headers | |
| 2x USB 2.0/1.1 Headers | |
| 1x Noise Detection Header | |
| 1x GIGABYTE Add-In Card Connector | |
| 1x Trusted Platform Module (TPM) Header (2×6 pin, for the GC-TPM2.0_S Module Only) |
|
| 1x Power Button | |
| 1x Reset Button | |
| 2x BIOS Switches | |
| 2x Temperature Sensor Headers | |
| 1x Clear CMOS Jumper | |
| Voltage Measurement Points | |
| Back Panel Connectors | 1x Q-Flash Plus Button |
| 1x Clear CMOS Button | |
| 2x SMA Antenna Connectors (2T2R) | |
| 1x USB Type-C Port, With USB 3.1 Gen 2 Support | |
| 5x USB 3.2 Gen 2 Type-A Ports (Red) | |
| 2x USB 2.0/1.1 Ports | |
| 2x RJ-45 Ports | |
| 1x Optical S/PDIF Out Connector | |
| 5x Audio Jacks | |
| I/O Controller | iTE I/O Controller Chip |
| H/W Monitoring | Voltage Detection |
| Temperature Detection | |
| Fan Speed Detection | |
| Water Cooling Flow Rate Detection | |
| Overheating Warning | |
| Fan Fail Warning | |
| Fan Speed Control | |
| Noise Detection | |
| BIOS | 2x 128 Mbit Flash |
| Use of Licensed AMI UEFI BIOS | |
| Support for DualBIOS | |
| PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Operating System | Support for Windows 10 64-bit |
| Form Factor | E-ATX Form Factor; 30.5cm x 26.9cm |
| Warranty Information | |
| Warranty | Manufacturer’s Warranty |
