ASRock Intel Arc B580 SL 12GO Steel Legend 12GB OC GDDR6 Graphics Card – 90-GA5CZZ-00UANF
Full description ASRock.
- Clock: GPU / Memory
GPU Clock: 2800 MHz
Memory Clock: 19 Gbps - Key Specification
Intel® Arc™ B580 Graphics
12GB 192-bit GDDR6
Intel® Xe2-HPG Architecture
Intel® Xe Super Sampling 2 (Intel® XeSS 2)
| Specifications | |
| Brand: | ASRock |
| Series: | B Series |
| Model: | 90-GA5CZZ-00UANF |
| Technical Specs | |
| Chipset Manufacturer: | Intel |
| Interface: | PCI Express4.0 x8 |
| Engine Clock: | 2800 MHz |
| Xe-Cores: | 20 Xe2 Cores |
| GPU Architecture: | Intel Battlemage |
| Memory | |
| Memory Type: | GDDR6 |
| Memory Size: | 12GB |
| Memory Interface: | 192-bit |
| Memory Clock: | 19 Gbps |
| Software & Features | |
| DirectX: | DirectX 12 Ultimate |
| OpenGL: | 4.6 |
| Features: | Polychrome SYNC |
| Ultra-fit Heatpipe | |
| Stylish Metal Backplate | |
| Striped Ring Fan | |
| Triple Fan Design | |
| General | |
| Connectivity Ports: | 1x DisplayPort 2.1 port (UHBR13.5) 2x DisplayPort 2.1 ports (UHBR10) |
| 1x HDMI 2.1a port | |
| Multi-Monitor Support: | Yes |
| Maximum Digital Resolution: | 7680 x 4320@60Hz |
| Recommended Power Supply: | 650w |
| Power Connectors: | 2x 8-Pin PCI PEG Connectors |
| Form Factor: | ATX |
| Dimensions: | 298 x 131 x 51mm |
| Warranty Information | |
| Warranty: | 3 Year Warranty |
ASRock Intel Arc B580 SL 12GO Steel Legend 12GB OC GDDR6 Graphics Card – 90-GA5CZZ-00UANF
Contact us if you would like to enquire about this product.
