ASRock B550M WiFi SE DDR4 Micro-ATX AM4 AMD Motherboard
Full description ASRock.
- AMD AM4 Support for Ryzen 5000 Series
Built on the reliable AMD B550 chipset, this motherboard supports Ryzen™ 3000, 4000 G-Series, 5000 and 5000 G-Series processors, making it a powerful and affordable foundation for gaming or productivity PCs. - DDR4 Performance up to 4733+ MHz (OC)
Quad DIMM design supports up to 128GB DDR4 memory with XMP profiles, delivering fast multitasking and improved system responsiveness. - PCIe 4.0 x16 & Ultra M.2 Storage
Equipped with PCIe 4.0 x16 for modern graphics cards and an Ultra M.2 slot (PCIe Gen4 x4) for high-speed NVMe SSDs, ensuring fast boot and load times. - Integrated WiFi & Gigabit LAN
Onboard Intel® 802.11ac WiFi and Realtek Gigabit LAN provide flexible wired and wireless networking options for home or office setups. - Polychrome RGB & Solid Power Design
Features 8-phase power design, durable components, and multiple RGB/ARGB headers to support stable performance and custom lighting builds.
| Specifications | |
|---|---|
| Brand: | ASRock |
| Model: | B550M WiFi SE |
| Chipset: | AMD B550 |
| Socket: | AM4 |
| Form Factor: | Micro-ATX (24.4 cm x 24.4 cm) |
| CPU Support | |
| Supported Processors: | AMD Ryzen™ 3000 / 4000 G-Series / 5000 / 5000 G-Series |
| Memory | |
| Memory Type: | DDR4 |
| DIMM Slots: | 4 |
| Maximum Capacity: | 128GB |
| Memory Support: | Dual Channel, XMP, Up to 4733+ MHz (OC), Non-ECC |
| Expansion Slots | |
| PCIe x16 Slot: | 1x PCIe 4.0 x16 |
| PCIe x1 Slot: | 1x PCIe 3.0 x1 |
| M.2 (Key-E WiFi): | 1x M.2 Key-E (WiFi Module Installed) |
| Storage | |
| M.2 Slot: | 1x Ultra M.2 (PCIe 4.0 x4) |
| SATA Ports: | 4x SATA 6Gb/s |
| RAID Support: | RAID 0 / 1 / 10 |
| Networking | |
| LAN: | Realtek RTL8111H Gigabit LAN |
| Wireless: | Intel® 802.11ac WiFi |
| Bluetooth: | Bluetooth 4.2 |
| Graphics Outputs | |
| HDMI: | 1x HDMI 2.1 |
| DisplayPort: | 1x DisplayPort 1.4 |
| D-Sub (VGA): | 1 |
| Audio | |
| Audio Codec: | Realtek® ALC1200 7.1-Channel HD Audio |
| Audio Features: | Nahimic Audio, PCB Isolation Shielding |
| USB (Rear) | |
| USB 3.2 Gen1 Type-A: | 4 |
| USB 2.0: | 2 |
| PS/2 Port: | 1 |
| Internal I/O Connectors | |
| 24-pin ATX Power Connector: | 1 |
| 8-pin 12V Power Connector: | 1 |
| CPU Fan Header: | 1 |
| Chassis/Water Pump Fan Headers: | 3 |
| USB 3.2 Gen1 Header: | 1 |
| USB 2.0 Headers: | 2 |
| Front Panel Audio Header: | 1 |
| RGB Header: | 2 |
| Addressable RGB Headers: | 2 |
| SPI TPM Header: | 1 |
| Back Panel I/O Ports | |
| Antenna Ports: | 2 |
| PS/2 Mouse/Keyboard: | 1 |
| HDMI Port: | 1 |
| DisplayPort: | 1 |
| USB 3.2 Gen1 Type-A: | 4 |
| USB 2.0 Ports: | 2 |
| RJ-45 LAN Port: | 1 |
| Audio Jacks: | Line In / Line Out / Mic |
| BIOS | |
| BIOS Type: | 256Mb AMI UEFI BIOS |
| Operating System Support | |
| OS Support: | Windows® 10 64-bit / Windows® 11 64-bit |
| Warranty Information | |
| Warranty: | 3 Year Warranty |
ASRock B550M WiFi SE DDR4 Micro-ATX AM4 AMD Motherboard
Contact us if you would like to enquire about this product.
